“Enabling Simulation Systems for the Future”

Custom Embedded OS/Scheduler running at 20 Hertz

• 20 Hertz synchronized to the Linux RTC (Real Time Clock)

• Qdisk Messaging for inter-thread connectivity and network testing

• Asynchronous threads for independent processing

  • Thread priority adjustable

• Message logging (with added memory card)

• Error logging (fault isolation and recovery)

Runtime modes

• Standard (data collection and forwarding)

• Playback (for playing back recorded logs)

• Simulation (for host integration message generation)

Input / Output Options

• RS232 Serial Port

  • Standard Baud Rates (9600 to 115200)

  • Input from devices or output to host

• 10/100 Networking

  • Standard 802.3 protocol

  • OSI Layer 3 networking

• Wireless networking

  • Standard 802.11 B/G/N

  • OSI Layer 3 networking

• USB 2.0

  • SPP (Serial Port Protocol

Software Protocol

• Embedded protocol designed for speed and network latency issues

  • Fully documented

  • Checksum validation of data

• System scalable with hundreds of nodes and thousands of data elements
